Australian light steel framing house project prefab kitset homes nz
SantaRosa.House
5 bedrooms
3 bathrooms
1 living room
385.6 m²
The total area of Santa Rosa is about 140 square meters. The living room, kitchen, and dining room are all on the first floor, and there is a bedroom with a separate bathroom. On the second floor there is a lounge, two bedrooms and a toilet. The balcony on the second floor forms an open space, adding a sense of hierarchy to the overall building.
Quick Detail:
| Name | Luxury villa | Application | Villa for living |
| Color | Optional(For you to choose ) | Feature | 1. Flexible space design makes you comfortable.
2. Quick set-up and early check-in.
3. Green environmental protection materials, fire, and wind anti-earthquake. 4.Construction speed is fast and simple |
| Material | light steel and other parts material | Certificate | CE,ISO,SAA,ETC,ISO |
Product parameters:
930Project in ZheJiang China
Name: SantaRosa.House
NO: DEPBL-930#
Lenth: 8854mm
Width:8754mm
Ground floor area: 77.5 ㎡
Fisrt floor area: 77.5 ㎡
Total area: 155㎡
Project date: 2020/8
Supplier:DeepBlue
Description:
Main structure: Light Steel
Wall material: ALC panel/fiber cement cladding+MGO board/gypsum board
Insulation material: Insulation material
Structure: Steel Frame
Ceiling material: MGO board/gypsum board
Floor/foundation material: laminate flooring/wooden/PVC carpet
Door: steel security door/WPC or plywood door
Window: aluminum alloy/PVC
Roofing: EPS sandwich panel/steel roofing/asphalt shingle
Other fittings: toilet, washbasin, shower, kitchen, etc.
Lifetime: 100 years of structure
Product Description
DeepBlue steel structural prefab villa is based on a light gauge steel frame system with high-performance finishing materials. The whole house can be assembled within a couple of hours by 4workers. the materials are the following: 1. Main structure: 89mm light gauge steel framing system based on AS/NZS 4600 standard. the structure can be design to resist 50m/s wind and 9degree earthquake.
2. Roof structure: 89mm light gauge steel truss system.
3. Chassis: 89mm light gauge steel flooring chassis 4. flooring: 18mm fiber cement board with vapor barrier and bamboo flooring or wooden flooring, PVC carpet, etc. 5.Wall cladding: 16mm PU insulated steel sandwich panel with beautiful decoration 6. interior lining: 9m fiber cement board,water-proof,termite-proof, security and healthy
7. ceiling: 8mm PVC ceiling panel
8. insulation: 89mm glass wool insulation with good soundproof performance.
9.windows: PVC sliding windows
10.exterior door: high-quality aluminum sliding windows 11.interior door: painted wood door 12.bathroom: shower, washbasin, toilet included
Company Introduction:
Since establishing the company in 2009, we have been proud of providing cost-effective custom and modular houses, apartments, and commercial buildings to people all over the world. So far, we have built more than 5,000 houses and won many design and construction awards. Today, we build, sell, finance, and lease our buildings from China to all around the world.
We specialize in the design and manufacture light steel frame house, include a light steel frame villa, modular house, apartment, resort, tiny house, etc.
We have a new large-scale processing center and modern production workshop to produce high-quality products in strict accordance with technical specifications and quality control, ensuring the accuracy of our products.
